STOMP™

FUNCTIONS

Power ON / OFF:

Press and hold the “O” button for 2s. If not connected to a Bluetooth®

device or connected but idle (not playing audio) the speaker will turn OFF

automatically after 15 min.

Play / Pause:

Press the “►” button once to play or pause audio.

Volume Up:

Press “+” button to increase the volume.

Volume Down:

Press “-” button to decrease the volume.

Next Track:

Press and hold “+” button for 2s to skip track.

Previous Track:

Press and hold “-” button for 2s to go to last track.

Bluetooth® Pairing:

Press and hold the “Bluetooth®” button for 2s to enter Bluetooth® Pairing

Mode. The speaker will disconnect from any paired device and will become

available to pair to new devices. The speaker will stay in pairing mode for 60s,

or until connected. Status LED will blink blue while in Bluetooth® Pairing Mode.

True Wireless Stereo Pairing:

Press the “TWS” button on any two Stomp™ speakers to pair them together

and play audio in stereo. Status LED will be cyan to indicate Right channel and

yellow to indicate Left channel.

Exit True Wireless Stereo Mode:

Press the “TWS” button to exit TWS pairing.

SKDY Multi-link™ Transmitting:

First, connect to the Stomp™ speaker by BT, AUX, or USB-A audio input

connection. Double press the "Multi-link™" button to set the speaker as

transmitting. Any receiving speaker enabled SKDY Multi-link™ will now be able

to join. Status LED will be purple.

SKDY Multi-link™ Mode Receiving:

Single press the “Multi-link™” button to set the speaker as receiving (the

speaker will automatically disconnect from any paired Bluetooth® devices).

Status LED will be green. Up to 99 receiving speakers can be connected to a

single transmitting speaker.

Check Battery Status:

The 4 LED indicators show the battery level. Press and hold “+” and “-“ buttons

together for 1s to initiate a voice prompt of the battery level.

Light Show Mode

Press and hold the “Light Show” button for 2s to turn the light show ON or

OFF. Single press the "Light Show" button to cycle between different light

show modes.

Strobe Light ON/OFF

Double press the "Light Show" button to toggle the strobe light ON or OFF.

Dual-Device Connection:

You can pair two transmitting devices (mobile phones for example) to the

Stomp™ speaker at the same time to DJ together. Pause the music on the

first device to play a song from the second device.

Charge Out:

While the speaker is ON, plug a USB-C™ or USB-A cable into the appropriate

port to begin charging your compatible portable device automatically.

CHARGING THE STOMP™

Use the USB-C™ cable included to connect the speaker to an appropriate

power source to begin charging. The LED indicators will show the battery is

charging. When all 4 LEDs are ON the battery is fully charged.

Warning:

1. To avoid damage to the speaker and battery, it is important to only use a

power source that matches the power requirements listed on the speaker’s

rating label.

2. To avoid overheating, it’s recommended not to place the speaker in direct

sunlight, especially while charging and playing music.

Battery status indication (not charging):

0-5% - speaker is OFF all 4 LEDs are OFF

5-10% - 1st LED blinks white, status LED blinks red

10-25% - 1st LED is ON white, other LEDs are OFF

25-50% - 1st + 2nd LEDs are ON white, other LEDs are OFF

50-75% - 1st + 2nd + 3rd LEDs are ON white, other LEDs are OFF

75-100% - All LEDs are ON white

Battery status indication (while charging):

0-25% - 1st LED blinks white, other LEDs are OFF

25-50% - 1st LED is ON white, 2nd LED is blinking.

Other LEDs are OFF

50-75% - 1st + 2nd LEDs are ON white, 3rd LED is blinking.

Other LEDs are OFF

75-99% - 1st + 2nd + 3rd LEDs are ON white, 4th LED is blinking.

Other LEDs are OFF

100% - All 4 LEDs are ON white

CONNECTION PRIORITY

AUX > USB > BT (Bluetooth®)

To play from an AUX source, simply plug in an AUX cable to the speaker and

your audio source device. It will automatically have priority over USB and BT.

To play from a USB source, plug in a USB flash drive and make sure that AUX

is disconnected. It will automatically have priority over BT (but not over AUX).

To play from BT source, connect a Bluetooth® enabled device and make sure

that AUX and USB are disconnected.

TROUBLESHOOTING

Factory Reset

Press and hold "-" and "+" buttons at the same time for 10s to initiate factory

reset. The speaker will revert to factory settings and all previously paired devices

will be deleted. Status LED will blink between blue and red while resetting.

Low Battery

If the speaker’s battery is fully depleted, it may not turn ON immediately even

when connected to a power source. Please plug the speaker into an

appropriate power source and let it charge for at least 10 minutes before

turning it ON.

Speaker is not playing wirelessly

If the speaker is not playing audio although it’s connected to a Bluetooth™

device, it may be because of the audio connection priority. Disconnect any

AUX or USB-A connections to the speaker and try again.

SPECIFICATIONS

Bluetooth® Version：5.3

Battery Capacity: 11.1V/3600mAh

Charging Input: DC 5V/2.2A

Playtime: 12 hours (Based on 77dBSPL(c) with light show OFF)

Charging Time: 4.5-5 hours

Operating Range: 10M

Rated Power: 40W+10W

Audio Inputs: Bluetooth®, USB-A, Aux 3.5mm

Charging Outputs: USB-C, USB-A

Battery Standby Time: 365 Days

IPX Rating: IPX7 (water immersion of 1m, for up to 30 min)
